- Distance between linear smoke detector DLF150 and the reflectors: 8 to 150 m.
- With the included single reflector, a distance of up to 60 m can be monitored.
- With the available extension kit 33642, a distance of up to 120 m can be monitored.
- With the available extension kit 33644, a distance of up to 150 m can be monitored.
- Linear smoke detectors are suitable for monitoring large areas such as halls, tunnels, shopping centers, aircraft hangars, atriums, etc.
- Commissioning is conveniently done via Bluetooth using an iOS or Android device using the commissioning App “My Beam” which is free of charge.
- The Bluetooth communication is only active during commissioning.
- Relay version for connection via I/O modules to fire alarm control panels.
- Optional available with integrated heating: 34109
-Extensive accessories such as reflector heating, sunshade, mounting bracket and others are available.
- Maximum detection angle: +/- 7° horizontal, +/- 4° vertical.
- The sensitivity of the linear smoke detector DLF150 can be adjusted and diagnostic values read using the "My Beam" commissioning app.
